Jackery SolarSaga 80W Solar Panel

FEATURES
TECH SPECS
FAQ

Jackery SolarSaga 80W Monocrystalline Solar Panel - converts solar to renewable energy with this dual-sided panel! Designed with extra-white glass used on the back panel, boosting conversion efficiency to an industry leading 25%. It's perfectly suited for outdoor activities and additionally for emergency power outages, with the solar panel weighing just 5.1 kg. It's lightweight, IP68 waterproof rated, and has an easy to carry handle. There are also rubber bumpers on each corner, preventing accidental damage during transport.

Featured Summary

World’s First Consumer Photovoltaic (PV) Modules Certified by TÜV SÜD

The world's first photovoltaic product to be certified by TÜV SÜD under the prestigious IEC TS63163 standard. Industrial-grade photovoltaic materials were used, with 15 professional tests completed.

Dual-Sided Panels - Enhanced Solar Efficiency

The upgraded solar panel can generate power from both sides. The use of extra-white glass (92% transmittance rate) on the back panel aids in the conversion rate.

Extensive Compatibility

The 80W Solar Panels are fully compatible with all Jackery Power Stations, providing first-rate charging options with up to 12pcs of 80W solar panels charged at the same time. You can charge in any way you want.

Made of 2.8mm low iron full toughened glass, the solar panel is extremely durable.

Water and Dust Resistance

IP68 waterproof and dustproof certification against harsh weather. A two-meter extension cable is included for an increased charging distance and is flexible enough for outdoor use.

Spec in Pictures

SolarSaga 80W

Dimensions: 90,6 x 52,81 x 2,69 cm

Ports

USB-A Output: No

USB-C Output: No

Solar

Peak Power: 80W

Power Voltage: 22.2V

Power Current: 3.55A

Open Circuit Voltage: 27.2V

Short Circuit Current: 3.65A

Dimensions

Folded: /

Unfolded: 916 x 528 x 27 mm

Weight: 5.1 kg

General

Warranty: 3 Years

Materiales: Monocrystalline Silicon Solar Cells

Waterproof: IP68

Efficiency rate: 25%

Operating temperature: -10-65℃(14-149°F)

In The Box

1x SolarSaga 80, 1x 2m Extension Cable, 1x User Manual, 1x Storage Case

Portable Power Station

Explorer 2000 Pro: Up to 10 pcs(with 2 solar connectors)

Explorer 1000 Pro: Up to 12 Pcs (with 2 solar connectors)

Explorer 500: Up to 1 Pc

Explorer 240: Up to 1 Pc

User Manual

BATTERY INFO

Jackery SolarSaga 80W Solar Panel.pdf

DOWNLOAD

Jackery SolarSaga 80W Solar Panel.pdf

DOWNLOAD

Notice

1. Solar Recharging time varies from different location, temperature, weather etc. The actual time may be different.

2. During solar recharging, keep your portable power station away from heat and direct sunlight in order to extend its life span.

3. Avoid contact with corrosive substances during storage, keep away from fire and heat sources. Avoid storing with sharp objects at the same time.

FAQ

Q: How can I use the double-sided power generation function of the 80W solar panel?

The solar panel 80W comes with a reflective carrying case. It features double-sided power generation through the reflective optical fiber, and reflective angle can be adjusted, through the sticking position of the magic tape of the carrying case.

Q: Can I use the 80W solar panel to recharge other Jackery models?

Yes, the 80W solar panel is compatible with all Jackery power stations model.

Q: Is the 80W Solar Panel waterproof?

The 80W solar panel is waterproof with the IP68 rating, however note the port is not waterproof.

Q: Is the glass on the back of the 80W board dangerous?

The solar panel glass is fitted with a special structure design, with no glass slag generated - rest assured the product is extremely safe.

Q: Why is there no functional logo on the silicone cover?

The silicone cover is mainly dustproof - there's a function mark at the switch button.

Q: Is the silicone cover removable/replaceable?

Unfortunately the cover cannot be disassembled. The silicone cover is designed together with the product body preventing loss.

Q: What certifications does the 80W have?

It comes with the IEC TS63163.

Q: Where is the 2-meter extension solar cable of the 80W located?

The cable is located in the side pocket of the carrying bag.

Q: Is there a DC extension cable for the solar panel?

We have the 5-meter extension cable - please check the link: https://ca.jackery.com/products/dc-extension-cable-for-solar-panel.

FAQ

Q: How can I use the double-sided power generation function of the 80W solar panel?

Q: Can I use the 80W solar panel to recharge other Jackery models?

Yes, the 80W solar panel is compatible with all Jackery power stations model.

Q: Is the 80W Solar Panel waterproof?

The 80W solar panel is waterproof with the IP68 rating, however note the port is not waterproof.

Q: Is the glass on the back of the 80W board dangerous?

The solar panel glass is fitted with a special structure design, with no glass slag generated - rest assured the product is extremely safe.

Q: Why is there no functional logo on the silicone cover?

The silicone cover is mainly dustproof - there's a function mark at the switch button.

Q: Is the silicone cover removable/replaceable?

Unfortunately the cover cannot be disassembled. The silicone cover is designed together with the product body preventing loss.

Q: What certifications does the 80W have?

It comes with the IEC TS63163.

Q: Where is the 2-meter extension solar cable of the 80W located?

The cable is located in the side pocket of the carrying bag.

Q: Is there a DC extension cable for the solar panel?

We have the 5-meter extension cable - please check the link: https://ca.jackery.com/products/dc-extension-cable-for-solar-panel.
